Features and advantages
- Three inputs and three outputs, supporting 380/400/415V, 50-60HZ power grid system
- Pure online double conversion, providing the best power supply quality, suitable for various loads, and high overload capacity
- Ultra-wide input voltage range, adapt to harsh grid environment
- Intelligent battery management to extend battery life
- Large LCD display in Chinese and English interface, friendly man-machine interface
Product performance
- Standard voltage: 380/400VAC
- Standard frequency: 50-60HZ
- Power factor: 0.8
Scope of application
- Medium-sized IDC Data Exchange Center Computer Room
- Medium-scale network management system
- Bank and Securities Implementation Center
- Industrial Process Control Application
- Traffic control and other areas
Specifications:
|
Model |
AGP003L 10-200KVA |
||||||||||||
|
Rated Capacity |
10KVA |
15KVA |
20KVA |
30KVA |
40KVA |
60KVA |
80KVA |
100KVA |
120KVA |
160KVA |
200KVA |
||
|
9KW |
13.5KW |
18KW |
27KW |
36KW |
54KW |
72KW |
90KW |
108KW |
144KW |
180KW |
|||
|
Rated voltage |
380V Three-phase four-wire + ground |
||||||||||||
|
Rated frequency |
50-60HZ |
||||||||||||
|
AC input |
|
||||||||||||
|
Voltage range |
380V±25% Three-phase four-wire + ground |
||||||||||||
|
Frequency Range |
50-60HZ ±5% |
||||||||||||
|
Soft start |
0-100% 5sec |
||||||||||||
|
Power factor |
﹥0.99 (With input filter) |
||||||||||||
|
Bypass input |
|
||||||||||||
|
Voltage range |
380V±25% Three-phase four-wire + ground |
||||||||||||
|
Frequency Range |
50-60HZ ±10% |
||||||||||||
|
Inverter bypass |
(overload) 0ms |
||||||||||||
|
Output |
|||||||||||||
|
Voltage accuracy |
380V±1% (Steady-state load), 380V±3%(Steady-state fluctuation) Three-phase four-wire + ground |
||||||||||||
|
Frequency accuracy |
50-60HZ Battery powered |
||||||||||||
|
Power factor |
0.9 (Lagging) |
||||||||||||
|
Waveform distortion |
Linear load is less than 3%, non-linear load is less than 5% |
||||||||||||
|
Steady-state response time |
﹤10ms |
||||||||||||
|
Overload capacity |
100% load can run normally, 125% 10min; 150% 1min |
||||||||||||
|
battery |
|
||||||||||||
|
Nominal battery voltage |
360V or 384V (optional) |
||||||||||||
|
Float voltage |
405V |
||||||||||||
|
Cut-off voltage |
315V |
||||||||||||
|
Maximum discharge current |
28A |
42A |
56A |
85A |
113A |
169A |
225A |
282A |
338A |
381A |
507A |
||
|
Recharging current |
1-50A (Can be set according to battery configuration capacity) |
||||||||||||
|
Display layout |
|
||||||||||||
|
Display |
LED, LCD display |
||||||||||||
|
Alarm |
Sound and light alarm |
||||||||||||
|
Protection |
UPS overcurrent, short circuit, low battery, filtering |
||||||||||||
|
Working environment |
|
||||||||||||
|
Temperature |
0-40 ℃ |
||||||||||||
|
Humidity |
0-90% No condensation |
||||||||||||
|
Storage temperature |
–25–70 ℃ (Without battery) |
||||||||||||
|
Noise |
60–65 db |
||||||||||||
|
Physical features |
|
||||||||||||
|
Weight (KG) |
Net weight |
200 |
224.7 |
224.7 |
354.8 |
412.3 |
513.9 |
700 |
860 |
900 |
1250 |
1380 |
|
|
Gross weight |
226.8 |
251.5 |
251.5 |
389.5 |
447.5 |
552.3 |
740 |
900 |
960 |
1310 |
1400 |
||
|
Dimensions (mm) width*depth* height |
450×730×1140 |
450*796*1230 |
525*790*1230 |
1100×860×1680 |
1500×1140×1800 |
||||||||
